23
BATTERY CHARGER
The battery charger and charging cables allow
you to charge both the transmitter and receiver at
the same time.
The battery charger is designed for a 110-volt
wall outlet. (European 220-volt AC chargers and
12-volt field charger for your automobile are also
available).
To use the battery charger for the two-dog
unit, combine both sets of battery charging
cables as shown. This enables you to charge the
transmitter and both receivers at the same time.
BATTERY CHARGER
Charging Cable
110 volt
Charger
Two-dog
unit only
22
COLLAR
Receiver Battery Charging Receptacle
On the inside of the collar, next to the collar
strap, is a battery charging receptacle with a
rubber cover plug.
Internal Antenna
The has no external
antenna on the collar. The Antenna is inside the
collar receiver.
Receiver
Charging
Receptacle
