34
TRANSMITTER
BELT CLIP ACCESSORY
Fig. 1.
Fig. 2.
35
OPTIONAL ACCESSORY BELT CLIP
1) Remove the clip bracket from the rear case. Fig.1.
2) Insery the belt clip post into the clip bracket
(uward as shown) and then retighten the bolts.
Fig.1.
3)Attach the belt clip onto the belt clip post.(As
shown)Fig.2
4)When you separate the transmitter from the belt
clip, pull upward on the transmitter while pushing
downward on the locker.(As shown) Fig.2
BELT CLIP ACCESSORY
Rear case
Clip bracket
Bolt
Locker
Belt clip post
Belt clip
