PARTS LIST

COMPACT DRIVE MECHANISM

700426

Ref.
Réf.

English description

Description française

Qty.
Qté.

Part #

Pièce #

1 Idler arm

Bras de tension

1

104518

2 Flat pulley

Poulie plate

1

102839

3 Flange washer

Rondelle à bride

1

102969

4 Double pulley inc. 102736 & 102782

Poulie double inc. 102736 & 102782

1

102692

5 Sleeve

Douille

1

102782

6 Bearing

Roulement à billes

2

102736

7 V-Belt , B-137

Courroie en V , B-137

1

104521

8 V-Belt , A-57

Courroie en V , A-57

1

103037

9 Spring

Ressort

1

102304

10 Drive frame

Châssis d'entraînement

1

104519

11 Pin

Goupille

1

104520

12 Hair pin 2.5mm

Goupille à ressort 2.5mm

2

102013

13 Nylon insert lock nut 5/8" n.c.

Écrou à garniture de nylon 5/8" n.c.

1

O/L

14 Nylon insert lock nut 3/8" n.c.

Écrou à garniture de nylon 3/8" n.c.

1

O/L

15 Flat washer 7/16" hole

Rondelle plate 7/16" trou

1

O/L

16 Hex. bolt 5/8" n.c. x 5 1/2"

Boulon hex. 5/8" n.c. x 5 1/2"

1

O/L

17 Carriage bolt 3/8" n.c. x 1 3/4"

Boulon à carrosserie 3/8" n.c. x 1 3/4"

1

O/L

O/L = Obtain Locally
