Parts list – Bercomac Subframe & Drive Mechanism for JOHN DEERE Series X300 User Manual

Page 21

background image

19

Ref.
Réf.

English description

Description française

Qty.
Qté.

Part #

Pièce #

1

Pivot support

Support de pivot

1

104510

2

Left support

Support gauche

1

104505

3

Right support

Support droit

1

104506

4

Pin

Goupille

1

104513

5

Cab support

Support de cabine

1

104508

6

Link

Lien

1

104730

7

Adjusting nut

Écrou Ajustable

1

104731

8

Link

Lien

1

104512

9

Lift support

Support de relevage

1

104507

10

Lift lever

Levier de relevage

1

104538

11

Intermediate arm

Bras intermédiaire

1

104535

12

Handle support

Support de manivelle

1

104509

13

Plastic grommet

Oeillet de plastique

1

102063

14

Lift stirrup

Étrier de relevage

1

104537

15

Left spring lock

Ressort de barrure gauche

1

102208

16

Right spring lock

Ressort de barrure droit

1

102209

17

Spring bracket

Fixation du ressort

2

102210

18

Handgrip

Poignée

2

102248

19

Bushing

Coussinet

1

104539

20

Delrin bushing

Coussinet Delrin

2

104540

PARTS LIST

SUBFRAME 700425-1

21

Knob

Bouton

1

102020

22

Key 3/16 x 3/16 x 1 1/2"

Clé 3/16 x 3/16 x 1 1/2"

1

104536

23

Pin

Goupille

3

103077

24

Lift pin

Goupille de relevage

1

102780

25

Hair pin 2.5mm

Goupille à ressort 2.5mm

4

102013

26

Hair pin 3mm

Goupille à ressort 3mm

1

102617

27

Cotter pin 5/32" x 1"

Goupille fendue 5/32" x 1"

2

O/L

28

Hex. bolt 5/16" n.c. x 1"

Boulon hex. 5/16" n.c. x 1"

2

O/L

29

Flange nut 5/16" n.c.

Écrou à bride 5/16" n.c.

2

O/L

30

Hex. bolt 3/8" n.c. x 1 1/4"

Boulon hex. 3/8" n.c. x 1 1/4"

1

O/L

31

Flange nut 3/8" n.c.

Écrou à bride 3/8" n.c.

1

O/L

32

Hex. bolt 5/8" n.c. x 1 1/4"

Boulon hex. 5/8" n.c. x 1 1/4"

2

O/L

33

Stover lock nut 5/8" n.c.

Écrou de blocage 5/8" n.c.

2

O/L

34

Square head set screw 5/16" n.c. x 1/2"

Vis à pression à tête carrée 5/16" n.c. x 1/2"

2

O/L

35

Flat washer 7/16" hole

Rondelle plate 7/16" trou

3

O/L

O/L = Obtain Locally
