Collection Windows Table Screen
User Guide | 55
FrcSz The fraction size for the current window (min,
ml, drops). The header for this column is also a
menu that can be used to change the fraction
size units to min, ml, or drops.
Thold The threshold value for each collection window.
Table 18. Collection Windows Table Screen function keys
Function Key Function
Done Saves any changes, contingent upon pressing
Done on the Advanced Collection screen, and
exits the Collection Windows Table screen.
Cancel Aborts all changes and returns to the Advanced
Collection screen.
Insert Inserts a new window at the position pointed to
by the cursor.
Caution: If 20 windows are defined, pressing
Insert causes window #20 to be deleted.
Delete Deletes a window at the position pointed to by
the cursor.
New Deletes all windows.
Table 17. Collection Windows Table screen parameters, continued.
Parameter Function
