Bio-Rad BioFrac™ Fraction Collector User Manual
Page 27
Connecting Instruments and Devices to the BioFrac Fraction Collector
User Guide
| 19
To connect the fraction collector to the BioLogic LP system or
Model
EP-1
Econo
pump
1.
Connect system cable 15:
a.
Connect the cable’s 15-pin D connector to the port labeled I/O on the
fraction collector.
b.
Connect the mini-DIN connector to the port labeled Fraction Collector on
the BioLogic LP system or the port labeled
on the Model EP-1 Econo
pump.
2.
Connect system cable 3:
a.
Connect one of the cable’s mini-DIN connectors to the REC port on the
fraction collector.
b.
Connect the other mini-DIN connector to the port labeled Diverter Valve on
the BioLogic LP system or the port labeled
on the Model EP-1 Econo
pump.
3.
If you are connected to a BioLogic LP system, press Collector on the faceplate
and then press the MODEL softkey followed by the BIOFRAC (or 2128) softkey.
4.
When prompted to verify that an external valve cable is connected, enter Yes.
5.
Follow the procedure,
To run the fraction collector in LP/Econo mode on
.
