Run the Protocol
Getting Started Guide | 21
3. Specify the settings for your run in the Run Settings dialog box.
Select the type of plate you are using in the Plate Type field. Refer to the table
below for the description of the supported plate types.
Flat bottom
plate Bio-Plex Pro™ flat bottom plate (black plate comes
with Bio-Plex Pro assays, catalog
#171-025001)
Filter plate Millipore multiscreen plate (for example,
MSBVN1210)
PCR plate Bio-Rad low-profile unskirted PCR plate (for
example, MLL-9601)
Auxiliary plate Nunc PolySorp (for example, 475094), Nunc
MaxiSorp (for example, 445105)
4. (Optional) Specify a pre-run routine and a post-run routine.
Note: Bio-Rad recommends running the Wash Between Plates routine
between protocol runs. This is the default setting for Post-Run Routine.
5. Click Create/Run Protocols.
Plate Type Compatible Consumable
