Bio-Rad Experion™ Vortex Station II - Manual (Page 10)

10 122008
Cleaning
Only use cleansing agents as follows:
- Water containing tenside
- Isopropyl alcohol
Do not allow moisture to get into the appliance when cleaning.
Wear protective gloves during cleaning the devices.
Repair
In case of any malfunction disconnect the device.
Contact your local BIO RAD Laboratories Office.
In case of repair the device has to be cleaned and free from any
materials which may constitute a health hazard.
Cleaning/ Case of repair
Power supply
Input
V 100 - 240
A 0,8
Hz 50-60
Output Vdc 24
24W.LPS
(Limited power source)
Hz 50-60
Protection class 2 (double insulated)
Shaker
Operating voltage Vdc 24
mA 800
Power consumption, normal operation W 20
Power consumption, standby operation W 2
Motor-output power W 8
Drive EC - motor
Speed rpm 3200 + 1%,
definitely set
Speed adjustment none
Speed display none
Agitation stroke mm 4,5
Shaking motion horizontal, circular
Perm ambient temperature °C +5 bis +40
Perm. relative humidity % 80
Protection type acc. to DIN EN 60529 IP 21
Contamination level 2
Overvoltage category II
Operation at a terrestrial altitude m max. 2000
Dimensions total W x D x H mm 148 x 205 x 63
(without attachment)
Weight without supported load
kg 2,9
Max. supported load incl. attachment kg 0,5
Technical data
