PrimeProbe2 User Manual
4
Technical Specifications
Parameter Specification
Pipe Sizes 3.2 to 315.0 inches (80 mm to 8000 mm)
–
at 1/8 pipe
diameter (insertion depth) installation
Measurement Range Bi-directional from 0.03 to 16.40 feet per second (0.01 m/s
to 5 m/s) (Maximum may be lower based on insertion length
and pipe position.)
Accuracy; Point
Velocity
Flow
±
0.0066 feet per second (
±
2mm/sec) or
±
2%, whichever is
the greater.
Refer to ISO 7145-1982
Repeatability
±
0.5% of velocity
Flow Determination Assumes fully developed flow profile; ISO 7145-1982
reference
Measurement
Sampling
Continuous or programmable from 1 to 90 seconds
Minimum Fluid
Conductivity
5
µ
S/cm
Process Connection 1-inch (25-mm) BSP (British Standard Pipe)
Pipeline Pressure
Rating
232 psi
Sensor Material PTFE ( polytetrafluoroethylene)
Body Material SS304
Electrode Materials SS316
Flow Temperature 32
º
to 176
º
F (0 to 80
º
C)
Safety Probe fitted with anti-bounce chain
Pressure Tapping Female quick-release connector
Adjustment Method 5 mm Allen key (supplied by ADS)
–
fits all screws
Protection IP68
Batteries Type: Lithium batteries
Life:
≤
3 years (depending on sampling period and usage)
Output: Signal
Units
Connection
Pulses proportional to velocity/flow rate - maximum frequency
32 Hz
User-selectable
MIL-spec connector
Communications USB
