NOTE: Two possible motor return port
locations are shown.
NOTE: Two possible motor return port
locations are shown.
8000RT Series
8000R Series
Case
Drain
Motor
Return
Case
Drain
Motor
Return
IMPORTANT:
ALWAYS connect case drain first,
motor return second, then pressure line to prevent
motor damage. ALWAYS disconnect pressure
line first, motor return second, then case drain last
to prevent motor damage.
1-1/16-12
FJIC
1-1/16-12
MORB
Case Drain
If the tractor is not equipped with a 3/8” body
size ISO 16028 zero pressure female flat face
case drain coupler, then order and install John
Deere case drain kit part number RE222721.
Motor Return
If the tractor is not equipped with a 3/4” body
size ISO 7241-1 Series A female motor return
coupler, then order and install the following
parts:
Eaton Aeroquip P/N GG108-NP12-22
Parker P/N 12M22F8OMXS
Eaton Aeroquip P/N 2266-12-12
Parker P/N 12F65OMXS
connected to fan
motor return hose
from Great Plains
M22 x 1.5
MORB
1-1/16-12
MJIC
John Deere P/N RE248312
M22 x 1.5
MORB
M22 x 1.5
FORB
}
supplied with Great Plains
planters and air drills
(p/n 811-069C)
5.7”
NOTE:
Can use John Deere P/N RE248312 to
extend case drain coupler and motor return
coupler out from rear of tractor if needed.
}
connect to tractor
