45 X-Press Trailing Kit
Operating Instructions
AS2684
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 AS2520 DISTRIBUTOR HEAD ASSEMBLY 14
2 P02600 WASHER FLAT M10 24
3 P05534 NUT LOCK M10 12
4 P06403 BOLT M10x20 GR. 8.8 8
5 P10578 WASHER 3/8" SHAKEPROOF 4
6 P13961 BOLT U M10 GR8.8 71x88 4
7 P14483 CHANNEL - 2m 2
8 P14520 BOLT M10x70 GR8.8 4
9 P14573 D/RAIL LOCK NUT 8
10 P15821 OSR RAIL PIVOT 4
11 P15893 OSR RAIL MOUNT 4
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
SPR EAD ER BAR ASSEMBLY - X-PR ESS
4.0m F/ W
5. Parts & Assembly
