31 X-Press Trailing Kit
Operating Instructions
5. Parts & Assembly
AS3402 LIFT AXLE ASSEMBLY
XPT K
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P00789 BOLT M24x180 GR. 8.8 5
2 P01102 BOLT M16x70 GR. 8.8 4
3 P01901 BOLT M16x80 GR. 8.8 8
4 P02008 NUT LOCK M16 'TYPE T' 12
5 P02010 NUT LOCK M24 6
6 P02483 LYNCH PIN CAT 1 4
7 P02602 WASHER FLAT M16 24
8 P02604 WASHER FLAT M24 Ø50 12
9 P02608 WASHER FLAT M30 4
10 P03118 BOLT M24x300 GR. 8.8 1
11 P04127 BUSH SPRUNG - Ø40xØ32x25 2
12 P04753 BOLT M8x60 GR. 8.8 1
13 P08802 SHIM KIT 7 PIECE 1
14 P09142 CLAMP PLATE ¼" 3
15 P10096 BOLT M8x35 GR. 8.8 2
16 P10231 CLAMP STAUFF 3/8" 2 HOSE 4
17 P10636 BUSH SPRUNG - Ø40xØ31x20 8
18 P11644 DECAL - DO NOT RIDE 1
19 P11695 DECAL - GREASE 50 HOURS 1
20 P13387 DECAL - SIMBA 85x150 1
21 P13843 DECAL - X-PRESS 62x580 1
22 P14024 BACK PLATE 2
23 P14025 PIN Ø30x129 1
24 P14072 PIN Ø30x93 3
25 P16243 CYLINDER - Ø100x130 - 50 1
26 P16252 AXLE BRACE - XPTK 1
27 P16253 LIFT AXLE - XPTK 1
28 P16254 AXLE MOUNTING 1
29 P16542 RETAINING CLAMP 1
30 P16930 CLAMP PLATE M24x2H 2
