Page 29
29
X-Press Trailing Kit
Operating Instructions
5. Parts & Assembly
AS3606
D R AW BAR ASSEMBLY
XPT K
IT EM
PART NO
DESCRIPT ION
QT Y
COMMENT S
1
P00071
NIPPLE - GREASE
2
2
P00205
QUICK RELEASE MALE - ½" BSP
2
3
P01102
BOLT M16x70 GR. 8.8
4
4
P02008
NUT LOCK M16 'TYPE T'
6
5
P02263
DOWTY SEAL ½" BSP
2
6
P02483
LYNCH PIN CAT 1
2
7
P02600
WASHER FLAT M10
8
8
P02602
WASHER FLAT M16
12
9
P02608
WASHER FLAT M30
1
10
P02649
BOLT M16x90 GR. 8.8
2
11
P03686
ADAPTOR MALE - MALE ½"-3/8" BSP
2
12
P04127
BUSH SPRUNG - Ø40xØ32x25
3
13
P04423
LYNCH PIN CAT 3
2
14
P04753
BOLT M8x60 GR. 8.8
4
15
P05401
WASHER SPRING M6
2
16
P05534
NUT LOCK M10
6
17
P06641
ADAPTOR MALE - MALE 3/8"-3/8" BSP
2
18
P09092
HOSE STOWAGE PLATE
1
19
P09142
CLAMP PLATE ¼"
4
20
P10231
CLAMP STAUFF 3/8" 2 HOSE
8
21
P10293
BOLT M6x20 GR. 8.8
2
22
P10636
BUSH SPRUNG - Ø40xØ31x20
2
23
P11077
BOLT M10x50 GR.8.8
2
24
P11642
DECAL - ATTENTION
1
25
P11644
DECAL - DO NOT RIDE
1
26
P11645
DECAL - HAND TRAP
1
27
P11695
DECAL - GREASE 50 HOURS
2
28
P11697
DECAL - ANTI TAMPER
1
29
P12559
DECAL - UNBRAKED
1
30
P12690
BOLT M10x30 GR. 8.8
2
31
P13387
DECAL - SIMBA 85x150
2
32
P13843
DECAL - X-PRESS 62x580
2
33
P14025
PIN Ø30x129
1
34
P14520
BOLT M10x70 GR8.8
2
35
P14754
BALL CAT 3 LOWER Ø37
2
36
P14781
BUSH SPRUNG - Ø44xØ36x30
4
37
P14842-1
HA 3/8"X2500 F-F
2
38
P16246
LINKAGE ADAPTOR - XPTK
1
39
P16250
SPACER Ø60x38x10
2
40
P16283
PIN Ø16x83
1
41
P16284
HOSE PLATE
1
42
P16296
LOOM 4.3M - 12N M-F
1
43
P16854
BRACE FIXED EXTENSION
1
44
P16855
DRAWBAR - XPTK
1
45
P16856
LINKAGE BAR - 984mm
1
46
P16857
PARKING STAND
1
47
P16858
DRAWBAR BRACE - UPPER
1
48
P16864
PIN Ø36x225
1
49
P16865
PIN Ø36x230
1
50
P16925
BUSH - Ø39.75mm
2
