564-070M 04/28/2014
32 FH6000HD Great Plains Manufacturing, Inc.
Appendix A - Reference Information
Specifications and Capacities
Model FH6400HD Specifications and Capacities
Model FH6600HD Specifications and Capacities
Model FH6424HD
Working Width (Swath) 24ft. 0in. (7.32 m)
Tooth Size 6 inch (15.2 cm), plus 2½in (6.4 cm) thread, diamond-shaped forge-hardened
Tooth Spacing 9 in. tooth-to-tooth, 11 in. bar-to-bar, 12 bars standard (16 optional)
Teeth Per Foot of Width 16.0 (Standard 12 bar), 21.3 (Optional 16 bar)
Field Length 38ft. 0in. (11.58 m)
Field Width (Span) 25ft. 6in. (7.77 m)
Transport Height (Folded) 10ft. 10in. (3.30 m)
Transport Width 12ft. 8in. (3.86 m)
Transport Length 22ft. 0in. (6.71 m)
Transport Clearance 11.3 in. (28.6 cm)
Weight Range 4,050 - 4,550 lbs (1830 - 2060 kg)
Tongue Weight 480 lbs (220 kg)
Hitch Category IV; Category III or Clevis with included accessories
70 - 100 hp (55 - 75 kW)
1. Power requirements vary significantly with conditions and practices.
Tractor Power Required¹
Model FH6630HD FH6636HD FH6642HD
Working Width (Swath) 30ft. 0in. (9.14 m) 36ft. 0in. (10.97 m) 42ft. 0in. (12.80 m)
Tooth Size 6 inch (15.2 cm), plus 2½in (6.4 cm) thread, diamond-shaped forge-hardened
Tooth Spacing 9 in. tooth-to-tooth, 11 in. bar-to-bar, 12 bars standard (16 optional)
Teeth Per Foot of Width 16.0 (Standard 12 bar), 21.3 (Optional 16 bar)
Field Length 38ft. 0in. (11.58 m) 38ft. 0in. (11.58 m) 38ft. 0in. (11.58 m)
Field Width (Span) 31ft. 6in. (9.60 m) 37ft. 6in. (11.43 m) 43ft. 6in. (13.26 m)
Transport Height (Folded) 10ft. 10in. (3.30 m) 10ft. 10in. (3.30 m) 10ft. 10in. (3.30 m)
Transport Width 12ft. 8in. (3.86 m) 12ft. 8in. (3.86 m) 12ft. 8in. (3.86 m)
Transport Length 22ft. 0in. (6.71 m) 22ft. 0in. (6.71 m) 22ft. 0in. (6.71 m)
Transport Clearance 11.3 in. (28.6 cm) 11.3 in. (28.6 cm) 11.3 in. (28.6 cm)
Weight Range 5,000 - 5,650 lbs 6,000 - 6,450 lbs 6,200 - 6,700 lbs
2270 - 2570 kg 2720 - 2930 kg 2810 - 3040 kg
Tongue Weight 600 lbs (270 kg) 820 lbs (370 kg) 1,200 lbs (540 kg)
Hitch Category IV; Category III or Clevis with included accessories
90 - 140 hp 110 - 170 hp 125 - 195 hp
65 - 105 kW 80 - 125 kW 95 - 145 kW
1. Power requirements vary significantly with conditions and practices.
Tractor Power Required¹
