2015P and 2515P
173-208M 4/11/2005
32
Shutting Off Seed Flow
Refer to Figure 32
Figure 32 shows the sliding seed tubes in the
open position. To shut off seed flow, move tubes
forward. The following instructions explain how to
shut off seed flow to each meter.
Refer to Figure 33
1. Remove the retaining clip and pull pin. Do not
remove cotter pin.
Refer to Figure 34
2. Move meter cap to position seed tube over
shut off pad.
3. Place pin in hole of meter cap and install re-
taining clip.
4. Repeat steps 1 through 3 for each meter.
NOTE: When pin with retaining clip is located in
the slot, sliding seed tube is open. When pin with
retaining clip is located in the hole, sliding seed
tube is closed.
Figure 32
Sliding Seed Tubes in open position
18290
Shut off
Sliding seed
tubes
Figure 33
18302
Retaining
clip
Shut off
pad
Sliding seed
tube
Figure 1 18303
Retaining
clip
Sliding
seed tube
Figure 34 18303
