Page 27
Great Plains Manufacturing, Inc.
Appendix A - Reference Information
23
2013-05-23
133-029M
Small Seeds Metering
Ref. Part No.
Part Description
1.
133-001H
30’ 7 1/2 SGS BOX WELDMENT
133-002H
30’ 10 SGS BOX WELDMENT
133-003H
24’ 7 1/2 SGS LH BOX WELDMENT
133-004H
24’ 7 1/2 SGS RH BOX WELDLMENT
133-005H
24’ 10 SGS BOX WELDMENT
133-006H
SGS END MOUNT WELDMENT LH
133-007H
SGS END MOUNT WELDMENT RH
2.
123-472H
24’ 2SNT SGS BOX LID WELDMENT
123-471H
30’ 2SNT SGS BOX LID WELDMENT
3.
123-356D
10’ EWNT SGS LID LATCH
4.
816-113C
LATCH KEEPER 37-15-061-17
5.
800-101C
RIVET POP 1/8 .125 AD42BSLF
6.
123-399D
24’ 2SNT 7 1/2 OUT SGS SHAFT
123-400D
24’ 2SNT 7 1/2INSIDE SGS SHAFT
123-401D
24’ 2SNT 10 SGS SHAFT
123-402D
30’ 2SNT 7 1/2 SGS SHAFT
123-402D
30’ 2SNT 7 1/2 SGS SHAFT
7.
817-010C
GRASS SEEDER SPROCKET
8.
805-067C
PIN COTTER 1/8 X 3/4
9.
804-012C
WASHER FLAT 3/8 SAE PLT
10. 817-008C
RPBY 817-504C
11. 817-009C
GRASS SEEDER SLEEVE
12. 804-042C
WASHER GRASS SEEDER CUP SHAFT
13. 803-007C
NUT LOCK 1/4-20 PLT
14. 800-028C
SNAP RING .875
15. 803-006C
NUT HEX 1/4-20 PLT
16. 816-112C
RUBBER LATCH 37-11-065-10
17. 123-118D
SEED ADJUSTMENT SUPPORT
18. 123-050H
ADJUSTMENT HANDLE PIVOT
19. 805-019C
PIN COTTER 5/32 X 1 PLT
20. 802-148C
HFSS 1/4-20X1/2 GR5
21. 803-001C
NUT HEX 10-24 PLT
22. 804-004C
WASHER INTERNAL STAR #10 PLT
23. 804-046C
WASHER FLAT #10 SAE PLT
24. 801-003C
SCREW RD HD SLT 10-24X1/2 PLT
25. 890-349C
3/8 SHAFT LOCKING COLLAR
FORMERLY 123-436D
26. 123-476H
REAR SEED RATE ADJ HANDLE WLD
27. 803-058C
NUT WING 5/16-18
28. 123-113D
LOCK TAB
29. 802-092C
RHSNB 5/16-18X3/4 GR5
30. 801-001C
SCREW RD HD 8-32 X 3/8 BRASS
31. 804-003C
WASHER FLAT #8 BRASS
32. 803-035C
NUT HEX 8-32 BRASS
33. 804-002C
WASHER INTERNAL STAR #8 BRASS
34. 123-410D
GAUGE MOUNTING BRACKET
35. 819-041C
SEED ADJUSTMENT GUIDE
36. 802-078C
HHCS 1/4-20X5/8 GR5
37. 804-006C
WASHER LOCK SPRING 1/4 PLT
38. 123-116D
SEED ADJUSTMENT SPOOL
39. 804-044C
WASHER MACH 1.38 X .876 X .048
40. 817-026C
HANGER DRIVE SHAFT
41. 123-473H
COUPLER DRIVE SPROCKET WELD
42. 803-088C
NUT HEX LOCK 1/4-20 FLG
43. 801-035C
SCREW SET 5/16-18 SKT KP X 3/8
44. 123-190D
SEED CUP COVER
