Drive Bundles
Refer to Figure 5
Note: While installing your Small Seeds attachment, you
may need to refer back to the parts section of this
manual for more details and for positive
identification of related items not mentioned in
these instructions.
If your drill is equipped with an Agitator attachment, a
majority of the drive system is already in place. If your
drill is not equipped with an Agitator, one of the following
drive bundles must be ordered with any Small Grass
Seeder assembly:
Drive Installation
Refer to Figure 5
If your drill does not have 197-115A or 197-116A refer to
the following:
Install the two 1 inch bore bearings on the end of the
box frame and frame drive plate using the flangettes
and
5 ⁄
16
in -18 x 1 inch round head square neck bolts
and hardware as shown.
Slide the 1 inch jackshaft thru the bearing mounted on
the end of the box frame. Slip the shaft through the
19 tooth sprocket
and the 22 tooth sprocket . Then
slip it through the bearing attached to the frame drive
plate.
Attach the drive chain from the gearbox to the 1 inch
jackshaft around the 22 tooth sprocket . Align and
tighten the chain and idler sprockets.
If your drill is assembled with 197-115A or 197-116A
Small Grass Seeders and Agitator Drive assembly refer
to the following:
Remove the 1 inch jackshaft thru the box frame end
panel. Attach the 19 tooth sprocket
to the jackshaft
and jack shaft back thru the box frame end panel.
Final Drive Connection
Refer to Figure 5
Route the drive chain back to the jack shaft sprocket
and back to the 19 tooth sprocket . Attach the idler
bracket around the rear opener tube using the u-bolt
and hardware ( , . & ). Fasten the idler
sprockets to the bracket with the hardware shown
( , , , , & . After connecting the chain, check
alignment of the sprockets. Position and adjust the idler
sprockets as shown.
Once all chains are aligned, tighten all the hardware.
Part Number Description
197-115A
30’ Small Grass Seeds
and Agitator Drive Assembly
197-116A
24’ Small Grass Seeds
and Agitator Drive Assembly
4
3
2
1
12 13
20
13
12
21
12
7
11 8 9 10
16 7
22 17 15 5 6
