loose, slide the drill frames inward so that the
lugs welded to the drill frames are up tight against
the post angles. Tighten all the nuts on the U-bolts.
13. Attach frame adjustment link from the drill frame
to the pivot post using the clevis pin with hairpin
cotters. Pin to pin should be approximately
37 inches.
14. Locate drill transport stabilizer frame 86
1 ⁄
2
inches
from the outside edge of each box frame see
Figure 45. Using
5 ⁄
8
inch U-bolts , lock washers
and nuts , mount stabilizer to box frame. Repeat
for other side.
15. Adjust clevis end of pull bars so that the distance
from the center line to center line of pull bar pin holes
is approximately 134
1 ⁄
4
inches.
16. Mount pull bars to drill transport stabilizer frames
and tongue slide . With the tongue slide in the
back position against its stop, adjust pull bar lengths
so boxes are in line with one another and parallel to
the back edge of the mainframe.
17. Extend the main lift cylinder and place the
transport lock pins in the transport position
through the holes in the mainframe axle side tube.
18. Fold the drill making sure that the tongue slide
moves smoothly up the tongue. When drill boxes are
almost folding in, stop and adjust the post-frame
adjustment links on each box so that the tang
on
each drill transport stabilizer frame lines up with the
nest
on the front of the main frame. Fold drill
completely closed.
19. With tongue slide forward on the tongue and drill
folded completely, position the pull bar lock pin
across the top of the tongue slide. Adjust the
transport lock bolt
on top and front of tongue up
against lock pin with
1 ⁄
16
inch clearance and lock the
jam nut. This pin prevents the drill from unfolding
when in transport. DO NOT LOWER DRILL WHILE
IN FOLDED POSITION.
20. Check to see that all nuts are tightened. See
“Torque Values Chart” on page 67, for torque
specifications.
