Seed Flap Replacement
Refer to Figure 42
To replace a seed flap
, use a needle nose pliers or
similar tool to grasp “T” top of flap. Pull upward to pull
flap up out of metal bracket
.
Push new seed flap down through metal bracket
until flap snaps into place with “T” top resting on top of
bracket.
Seed Flap Replacement Older Style
Refer to Figure 43
1.
Remove one disk for easier seed flap replacement.
2. To replace, pull the seed flap up out of metal
bracket .
3. Push new seed flap down through metal bracket
until seed flap is in place.
Figure 42
816-302C Seed Tube Flap
31047
2
1
1
2
1 2
Figure 43
817-349C Seed Tube Flap
18398
2
1
1
2
1
