60
Section 7 Specifications and Capacities
PT1230 Pull-Type Folding Planter 401-069M-B 4/12/05
Great Plains Mfg., Inc.
Section 7
Specifications and Capacities
*With markers
Type Pull Type
Row Spacing 30 inches
Rows per Unit 12
Weight 11,4000 pounds*
Drive Ground drive with contact drive wheel
Transmission End mounted
Frame Construction Steel tubing, double bar 5” x 7” x 3/8” wall and 7” x7” x 3/8” wall
Transport Width 15 feet
Length 18 feet 5 inches
Tires Gauge Wheel: 9.5 L X 15, 12-Ply; Contact Drive Wheel: 13-6.50 X 6
Tractor Requirements 160 horsepower
NOTE: Horsepower requirements will vary with field conditions, terrain and
planter options.
Row Specifications
Down-Pressure Springs, Standard Package Five-setting, quick-change springs; 1/4-diameter wire; 85 to 155 pounds
down force
Opener 15-inch double disks, double-ground and offset
Unit Body Shank welded, 7-gauge sheet metal; hopper support plate, 12-gauge sheet
metal
Parallel Linkage 1/2 x 2 arms, high-carbon steel
Depth Wheels 4 x 16
Closing Wheels or Disks 1 x 12 double-V closing wheels or 6.5-inch chevron wheel with closing disks
Depth Control 0 to 4 inches,1/4-inch increments
Hopper Capacity 2 bushels
Optional Liquid Squeeze Pump
Maximum speed 125 rpm
Maximum pressure 5 psi
Output per revolution 5/16-inch hose: 0.58 gpm; 1/2-inch hose: 1.4 gpm
NOTE: All tires are warranted by the original manufacturer. Tire warranty information can be found in the brochures in-
cluded with your Operator’s and Parts Manuals or online at the manufacturer’s websites. For service assistance or infor-
mation, contact your nearest Authorized Farm Tire Retailer.
Manufacturer Website
Titan www.titan-intl.com
Goodyear www.goodyearag.com
Firestone www.firestoneag.com
