Great Plains Manufacturing, Inc. Parts Lists 7
09/10/2007 195-066M
Existing Parts Affected
The following existing parts may be involved in the kit
installation. The Disposition column indicates whether
parts are left in place, moved or not re-used. The part call-out numbers in the list match all Figures in
the installation instructions. Descriptions match those in
your drill Parts manual.
Existing Parts List
Figure 8
Existing Parts Affected
27035
51 52
53
55
54
Callout Part No. Part Description Part Disposition
195-121D STEP LH Removed. Not re-used.
195-122D STEP RH Removed. Not re-used.
802-082C HHCS 1/2-13X1 3/4 GR5 Saved and re-used.
803-020C NUT HEX 1/2-13 PLT Saved and re-used.
804-015C WASHER LOCK SPRING 1/2 PLT Saved and re-used.
51
52
53
54
55
