© 2013 CDS-John Blue Co. 20
Clutch Kit
Parts List
ITEM PART DESCRIPTION PART #
-X050
MANUAL
-X058
ELEC.
-X059
HYD.
1 WASHER 115626-01 X X X
2 O-RING S-316 X X X
3 GREASE FITTING H-28 X X X
4 CLUTCH SPACER 115639-01 X X X
5 3” DOWEL PIN 115640-01 X X X
6 SHAFT EXTENSION 115638-01 X X X
7 THRUST WASHER 115651-01 X X X
8 ¼-20 X 1” SOCKET CAP SCREW 90512 X X X
9 SPROCKET RETAINER 115632-01 X X X
10 CLUTCH SPROCKET 18T-RC50 115637-01 X X X
11 CLUTCH BEARING 115650-01 X X X
12 CLUTCH CARRIER ASSY 115663-91 X X X
13 SPROCKET CARRIER ASSEMBLY 115664-91 X X X
14 2” DOWELL PIN 115194-01 X X X
15 CLUTCH COLLAR 115641-01 X X X
16 3/8” SQ KEY 115642-01 X X X
17 CLUTCH SPRING 108907-01 X X X
18 HAND WHEEL A-50 X X X
19 CLUTCH JAW ASSEMBLY 115662-91 X X X
20 KEY RETAINER – ROLL PIN S-4248 X X X
21 CLUTCH YOKE 115635-01 X X X
22 5/8” JAM NUT 92037 X X X
23 SHIFTER ROD 115643-01 X X X
24 CLUTCH MOUNTING PLATE 115993-91 X X X
25 5/16 X 1 HEX BOLT 90637 X X X
26 3/8 X 1-1/4 HEX BOLT 90653 X X X
27 TORSION SPRING 114165-01 X X X
28 BRACKET - THROW OUT L-3007 X
29 CAM - THROW OUT A-2757-A X
30 PAWL - THROW OUT A-2758-A X
31 SPRING – THROW OUT F-48 X
32 COTTER PIN 5/32” X 1” 94010 X
33 LEVER - THROW OUT L-3064 X
34 # 10 SQ NUT 92014 X
35 WASHER A-697 X
36 CAM ROLLER A-2762 X
37 ROLL PIN A-2763 X
38 2-1/4 RD HEAD SCREW 90953 X
39 3/8 NUT 92024 X
40 HANDLE SUPPORT 115661-01 X
41 5/16 – 18 HEX NUT 92020 X X X
42 5/16 LOCK WASHER 93023 X X X
43 5/16 FLAT WASHER 93010 X
44 MOUNT - ACTUATOR 115995-91 X
45 1-3/4” PIN 114002-01 X
46 COTTER PIN 1/16 X ½” 94002 X
47 BRACKET - SHIFTER 114001-01 X
48 ELECTRIC ACTUATOR 114003-01 X
49 2” PIN 114594-01 X
50 BRACKET - CYLINDER 115998-01 X
51 5/8 SAE FLAT WASHER 93016 X
52 PISTON 105463-01 X
53 CYLINDER 105449-01 X
54 HOUSING 105447-01 X
55 HYD CYLINDER REPAIR KIT 106531 KIT
56 HYD CYLINDER ASSEMBLY 113557-91 KIT
57 5/16 X 1-1/2 HEX BOLT 115158-01 X
58 3/8 X 1 HEX BOLT 90860 X
59 3/8 LOCK WASHER 93024 X X
60 3/8 X 4-1/2 HEX BOLT 90667 X
61 3/8 X 1-1/2 HEX BOLT 90655 X
62 5/16 X 1-3/4 SQ. HD BOLT 90554 X
N/S PULLEY A-2765 X
N/S ROPE – 12’ A-2766 X
