4 2014+ Single Fold Marker Front Parts Great Plains Mfg., Inc.
113-921M Front Parts 2013-10-16
Install Right Mount
Refer to Figure 5
10. Select one new:
113-902H MOUNTING BRACKET RIGHT
two new:
two new:
806-044C U-BOLT 5/8-11 X 5 1/32 X 6 GR5
and four sets new:
804-022C WASHER LOCK SPRING 5/8 PLT
803-021C NUT HEX 5/8-11 PLT
11. With the arm to the rear, flat plate up, loosely install
the mounting bracket on the rear wing tool bar,
just outboard (right) of the wing cylinder mount
tube
.
12. Adjust the initial position of the bracket for a
distance:
74.9 cm (29
1 ⁄
2
in.)
measured from the from right outside face of a
mount tab to the right rear end of the rear tool bar
(due to weld fillets, this measurement is
approximate).
Leave fasteners finger-tight until step 28.
Figure 5
Install Right Mount
31338
68
65
27
57
U
D
R
L
F
B
1
3
27
68
65
57
27
1
3
