Front Parts
Front Parts
Great Plains Manufacturing, Inc.
Corporate Office P.O. Box 5060
Salina, Kansas 67402-5060 USA
Existing Parts
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual. The Part Disposition column indicates whether the part is
re-used or discarded.
Abbreviations
Callout
Quantity
Required
Part Number Part Description
11 1
a
160-762D WSMB MODULE MOUNT PLATE
a This part is pre-installed on the implement and left in place.
B.C. Between Centers HHCS Hex Head Cap Screw
BRG Bearing JIC Joint Industry Conference (standard)
CP Coupler LG Long
CYL Cylinder LH Left Hand
EL Elbow MJIC Male JIC
EXT Extension MORB Male ORB
FJIC Female JIC NTA No-Till Air
FJIC Female JIC ORB O-Ring Boss
FLG Flange PLT Plated
FORB Female ORB QD Quick Disconnect
FTHD Full Threaded RH Right Hand
GR5 Grade 5 RHSNB Round Head Shank Neck Bolt
GR8 Grade 8 SAE Society of Automotive Engineers (standard)
GW Gauge Wheel USS United States Standard (heavy duty)
HEX Hexagonal WSMB Working Set MemBer
HH Hydraulic Hose X by
