Memory Last setting before power down is remembered
and restored on next power up. 9 user settable
flash rates.
Output Pulse 40 µsec positive/negative pulse (menu
selectable), 3.3 Vdc typical
Input Power Internal Rechargeable Batteries 6 Vdc, External
AC recharger (115 Vac to 230 Vac)
Light Output Average: 13 Watts typical > 4000 FPM
Instantaneous (per flash): 230 mJoule typical
to 4000 FPM
Flash Duration 10-25 microseconds (auto adjust with flash rate)
Flash Tube (Lamp) Life 100 million flashes
Run Time
2 hours typical at 1800 FPM, and over 1 hour at
6000 FPM with fully charged batteries
Charge Time 4-5 hours typical with PSC-pbxU
Weight 1.875 lbs [0.8505 kg] including batteries
This product is designed to be safe for indoor use under the following
conditions (per IEC61010-1).
Operating Temperature 32-104 ºF [0-40 °C]
NOTE: Safety thermal feature will set unit into TACH Mode (stops
flashing) in the event of internal overheating.
Humidity Maximum relative humidity 80% for temperature
up to 88 °F [31 °C] decreasing linearly to 50%
relative humidity at 104 °F [40 °C]
E-21
TABLA DE CONTENIDO TABLA DE CONTENIDO
1.0 VISTA GENERAL ........................................................................ S-1
1.1 Entrepaño del Despliegue/la Definicion de Botones ... S-1
2.0 PREPARACION PARA EL USO ................................................... S-3
2.1 Poder .................................................................................... S-3
2.2 De Entrada / Las Conexiones de salida ....................... S-4
3.0 MENU ......................................................................................... S-5
4.0 OPERACION ............................................................................... S-6
4.1 Modo Interno - La Operacion Estroboscopica Uniforme .... S-7
4.2 Modo Interno - El Generaor de la Frecuencia de TACH ..... S-10
4.3 Modo De Entrada Externo .............................................. S-10
4.4 Modo del Tacometro - La Entrada Externa Requirio ....... S-11
4.5 Modos Externos de la Demora (Fase que Cambia) ... S-11
4.6 Poder Arriba Caracteristicas ....................................... S-12
5.0 UTILIZAR EL ESTROBOSCOPIO PARA MEDIR RPM ............... S-13
6.0 LIMITACIONES DE SENSORES OPTICOS REMOTOS .............. S-15
7.0 El REEMPLAZO de LAMPARA Y FUNDE ................................. S-16
7.1 Reemplazo de lámpara .................................................. S-16
7.2 Funda .................................................................................. S-18
8.0 LA BATERIA ACCIONO LOS MODELOS SOLO ....................... S-18
8.1 Indicación baja de Batería ............................................. S-19
8.2 Cargar las Baterías ......................................................... S-19
8.3 Alimentación Corcel Externo ........................................ S-20
8.4 Disposición de Batería ................................................... S-20
9.0 ESPECIFICACIONES ................................................................ S-21
10.0 OPCIONES Y ACCESORIOS ..................................................... S-23
