Media:
Compact Flash to 2 GB
Display:
LCD Graphics 160 x 80 pixels black FSTN with White LED backlight
User controlled Backlight level and Contrast adjust (electronic)
Display Modes:
Trending (Horizontal), Large Dual Digital Readout, Mixed Mode
User Interface:
5 buttons keypad with 2
nd
Function operation
Clock:
Internal battery backed clock, with auto leap year and daylight
savings
Relay Output:
Two alarm outputs: 30V 0.5A Form A relays
Opto-isolated Input: One input 5 to 12Vdc operation @ 10mA typical.
Audible:
Internal buzzer (tones)
Dimensions:
Front panel 96mm x 96mm (1/4 DIN) x 152mm (3.78 x 3.78 x 6
inches).
Environmental:
Indoor Use Only
Installation Category II per IEC 664
Pollution Degree Level II per IEC61010-1
Altitude up to 2,000 m
Temperature -10 °C to 50 °C operating per IEC61010-1
Humidity Maximum relative humidity 80% for temperatures up to 31
°C decreasing linearly to 50% relative humidity at 40 °C.
Certification:
CE
– EN61326 EMI/EMC EN61010-1 Safety
UL and cUL (Power Supply)
Optional Communications
USB
Front panel USB 2.0 slave port for data transfer and configuration.
Ethernet
10/100 Ethernet
