pg 49 StreamNet Digital Media and System Design Reference Guide
Designing a StreamNet System,
example configurations
HDMI AVR
LAN CAT-5e+ CAT-5e+
Less than 50 kilometers
HDMI
PROJECTOR
HDMI
SOURCE
VIEW MLAV9500
DVI-to-HDMI
Adapter
HDMI Cable
Less than 15 Meters
Less than 15 Meters
HDMI Cable
Less than 15 Meters
HDMI Cable
VIEW VL9300
DVI Output Decoder
VL-CEC
VIEW VL9300
DVI Output Decoder
VL-CEC
AVR controls
are conducted
via optional
CEC control or
with decoder
IR/Serial/IP
provision(s)
and state
machine via
GPIO
HDMI
1.X Input
Projector controls are
conducted via optional
CEC control or with
decoder IR/Serial/IP
provision(s) and state
machine via GPIO
Source controls via encoder;
IR/Serial/Contact Closure/IP
provision(s) and sense
LAN CAT-5e+ CAT-5e+
Less than 50 kilometers
HDMI
PROJECTOR
HDMI
SOURCE
VIEW MLAV9500
DVI-to-HDMI
Adapter
HDMI Cable
Less than 15 Meters
Less than 15 Meters
HDMI Cable
SLX300
Other SpeakerLinX Amplifiers
VIEW VL9300
DVI Output Decoder
VL-CEC
Source controls via encoder;
IR/Serial/Contact Closure/IP
provision(s) and sense
SpeakerLinX Amplifier
connected directly to n
speakers
Projector controls are
conducted via
optional CEC control
or with decoder
IR/Serial/IP
provision(s) and state
machine via GPIO
HDMI source to destination AV flow and control scenarios
Scenario 5: HDMI source to HDMI display and HDMI (AVR) and StreamNet Control
Scenario 6: HDMI source to HDMI display and StreamNet Audio, and Control
