APPENDIX C – SINGLE PHASE TECHNICAL DATA
SINGLE PHASE
MAXIMUM AC AMPS (RMS)
SHIPPING DATA
FLX or SCR
Amp
DC
DC
120
208
240
480
600
Cabinet
WEIGHT
Model Numbers
Hour
Volts
Amps
VAC
VAC
VAC
VAC
VAC
Size
Lbs
KG
200-06-260S1 260
12 40
11.6
6.7
5.8
2.9
M4 79 36
200-06-475S1 475 12 75
21.0 12.5 10.8
5.4
4.3
2.3
M4 97 44
200-06-600S1
600
12
95
28.0
16.2 14.0
7.0
5.6
M4 101 46
200-06-865S1 865 12 135
22.6 19.6
9.8 7.8
M4 125 57
200-06-965S1 965 12 150
25.2 21.8
10.9 8.7
M4 154 70
200-09-475S1 475 18 75
16.9
14.6
7.3 5.8
M4 114 52
200-09-600S1 600 18 95
21.5 18.6
9.3 7.4
M4 119 54
200-09-865S1 865 18 135
30.5 26.4
13.2 10.6
M4 143 65
200-09-965S1 965 18 150
33.9 29.4
14.7 11.8
M4 178 80
200-12-260S1 260 24 40 19.7 11.3
9.8 4.9 4.0 M4
95
43
200-12-475S1 475 24 75
21.2 18.4
9.2 7.4 M4 134 61
200-12-600S1 600 24 95
27.0 23.4
11.7
9.4 M4 145 66
200-12-750S1 750 24 115
32.6 28.2
14.1
11.3
M4 163 74
200-12-865S1 865 24 135
38.3 33.2
16.6
13.3
M4 169 77
200-12-965S1 965 24 150
42.5 36.8
18.4
14.7
M4 198 90
200-18-260S1 260 36 40
16.0 13.8
6.9
5.5
M4
136
62
200-18-475S1 475 36 75
30.0 26.0 13.0 10.4
M4
158
72
200-18-600S1 600 36 95
37.9 32.9
16.4
13.1
M4 163 74
200-18-750S1 750 36 115
45.9 39.8
19.9
15.9
M5 216 98
200-18-865S1 865 36 135
46.6
23.3
18.7
M5 238 108
200-24-260S1 260 48 40
20.6 17.8
8.9 7.2 M5 132 60
200-24-475S1 475 48 75
38.6 33.4
16.7
13.4
M5 198 90
200-24-600S1 600 48 95
48.9 42.4
21.2
16.9
M5 242 110
*DC FUSE MUST BE A FAST ACTING FUSE CAPABLE OF PROTECTING SEMICONDUCTORS.
Charger Output Current (Amps)
DC Fuse Rating (Amps) (LET/LMT)
40
75
95
115
135
150
165
185
225
265
63
100
125
180
180
200
200
250
250
355
