Using the Manual Remote to Configure the Actuator
In the absence of an optional RS-232, USB, or serial interface, the manual remote can be
used to perform extensive actuator setup functions.
Accessing the Configuration Mode
To access the configuration mode, press and hold the HOME/SETUP button for 5 seconds.
Button Functions
• When a screen appears, a line will be highlighted. Use the UP and DOWN arrow keys to
highlight a different line.
• When the desired line is highlighted, press the HOME/SETUP button to enter that
value.
• For parameters such as number of ports or positions, use the arrow keys to toggle up
and down to the desired value, which is then entered by pressing the HOME/SETUP
button.
• Only two menus—the Interface Setup and Baudrate—have more than three options.
Use the arrow keys to scroll down to additional screens to select the desired value or
parameter.
• The UP arrow key also functions as a back button.
A complete menu tree appears on the next page.
Examples
To configure the actuator for a 10 position multiposition valve:
1. On the main menu, use the arrow buttons to highlight
Valve Setup. Press the HOME/SETUP button.
2. Use the DOWN arrow button to highlight Multiposition.
Press the HOME/SETUP button.
3. Use the UP and DOWN arrow buttons to move through the
numbers until 10 is showing. Press the HOME/SETUP button.
In the multiposition mode, “counterclockwise” means that the actuator moves in the
“positive” direction—position 1 to position 2. The clockwise direction is “negative”,
moving in the direction of position 2 to position 1.
To set our just-configured 10 position actuator to move in a clockwise direction:
1. On the main menu, use the arrow buttons to highlight
Valve Setup. Press the HOME/SETUP button.
2. Use the DOWN arrow button to highlight Move Direction.
Press the HOME/SETUP button.
3. Use the DOWN arrow button to highlight Clockwise.
Press the HOME/SETUP button.
���������
���������������
������������������
��������������
����������
����������������
��
�
�������������
�����������������
��������������
��
���������
���������������
������������������
��������������
����������
����������������
����������������
�����������������
��������������
��������������������
������������
�����������
