TO Toggles the actuator to the opposite position from its current position; i.e., if the
actuator is currently in Position B, it will toggle to Position A.
Modes available: Two position (1 and 2)
Example
Command:
TO
Causes the actuator to toggle from one position to the other
TT Timed toggle: the actuator will toggle from its current position to the opposite, wait
for a programmed amount of time, then toggle back to its original position.
Note: This command is ignored if DT=0. (See also DT command)
Modes available: Two position (1 and 2)
Example
Command:
TT
The actuator will initiate the timed toggle procedure
VRn Reports the current firmware version,
where n = [null] for the main PCB, or n = 2 for the serial interface PCB.
Modes available: All
Examples
Command:
VR
Returns: Current revision of the main PCB firmware
Command: VR2
Returns: Current revision of the serial PCB firmware
/? Displays the list of the primary commands for the actuator. The list is similar to the
serial command table above but is not inclusive of all the commands.
Modes available: All
Example
Command:
/?
Returns: The list of commands for the actuator
Optional Serial Interface
