2
Getting Started
Components of the M Series System
Check the contents of the packages against Figure 1 to verify that you have
received all of the components. Contact the factory if anything is missing
or damaged. (NOTE: damaged shipments must remain with the original
packaging for freight company inspection.)
Components include:
• Pump
Model M6: Product number CP2-4841-100D
Model M50: Product number CP3-8182-625D
• Motor assembly
Model M6: Product number CP-DSM
Model M50: Product number CP-DSM2
• MicroLYNX controller: Product number CP-CM1-P
• Controller motor power cable with 5 pin DIN connector
• Controller RS-232 ribbon cable
• 24 VDC power supply
• 110/220 VAC cable for power supply
• Fittings (2)
Model M6: Product numbers ZN1FPK (nut) and ZGF1PK (ferrule)
Model M50: Product numbers CFL-2BK-S (nut) and
CFL-CB2KF-S (bushing)
• M6-LHS software CD
• Manual
• Quality control certificate
PC System Requirements
Pentium PC 100 MHz or higher, running Windows 95, 98, ME, NT, 2000,
or XP. The pump controller requires a dedicated serial port. If your pump
system includes a valve with electric actuator, an additional serial port is
required. Alternately, a USB to RS-232 adapter (not supplied) can be used
for one or both connections. The adapter may be purchased from any
computer supply outlet.
