8
Figure 8: Setting the backlash and volume per revolution values
CLICK THE BOX AND ENTER THE
µL/REV FROM THE QC CERTIFICATE
CLICK THE BOX AND ENTER THE
BACKLASH VALUE FROM THE
QC CERTIFICATE
To override the factory default values for backlash and µL/rev:
1. Locate the backlash and µL/rev values on the QC certificate.
2. Click the Enable box under Backlash on the Setup screen, and type in
the backlash value.
3. Click the Use measured uL/rev box under Pump, and type in the volume
per revolution.
4. Click Apply, then Close.
Initial Setup
