Arcmaster 401mst power source, Arcmaster 401mst – Tweco ArcMaster 401MST User Manual
Page 45
ARCMASTER 401MST POWER SOURCE
Manual 0-5287
3-15
INSTALLATION, OPERATION AND SETUP
Graphic for TIG
I
Current
I1
Welding current
ISt
Hot start current
Iz
Short circuit
t
Time
tSt
Hot start
Art # A-12456
Figure 3-5 TIG Current Routing Diagram
ARCMASTER 401MST
Negative Welding
Terminal (-)
Work Lead
Positive Welding
Terminal (+)
19 Pin Control Socket
Tig Torch
Art # A-12550
Figure 3-6 Setup for TIG (GTAW) Welding
