Firepower SPOOL GUN OPERATING AND SAFETY MANUAL
12
7. Thread wire into inlet liner
8. Push and hold red drive roll pressure
release lever
9. Thread wire to the middle of drive rolls
10. Release red lever
11. Replace the spool cover and switch the
power source on
12. Turn the wire speed adjustment to
minimum wire speed (see page 13 )
13. Press gun trigger to feed wire through
outlet liner and out the end of the
contact tip 2” (50mm).
ƽWARNING — Never place finger over
end of gun. Wire may be driven through
finger
14. Install nozzle
15. Pressing gun trigger to feed wire, adjust
the drive roll pressure to provide smooth
wire travel without crushing the wire.
16. Cut off wire
