ULTRA-CUT 300 XT
3-32 INSTALLATION Manual 0-5305
3.20 Install Remote Arc Starter
Site Location
Select a clean, dry location with good ventilation and adequate working space around all components.
Review the safety precautions in the front of this manual to be sure that the location meets all safety requirements.
Interconnecting cables and hoses attach to the Arc Starter. There must be adequate space around the Arc Starter
for these connections without excessive kinking or bending.
Mounting Dimensions
NOTE
Height not shown is 7.375” ( 187mm )
