CUTMASTER 82
Manual 0-4979
OPERATION
4T-13
Type Torch: SL60 With Shielded Tip
Type Material: Aluminum
Type Plasma Gas: Air
Type Secondary Gas: Single Gas Torch
Thickness
Tip
Output
Amperage Speed (Per Minute)
Standoff
Plasma Gas Press
Flow (CFH)
Pierce
Pierce Height
Inches mm (Cat. No.) Volts(VDC)
(Amps)
Inches
Meters
Inches mm
psi*
bar
Plasma Total** Delay (Sec) Inches mm
0.032 0.8
9-8208
116
40
220
5.59
0.187 4.8
70
4.8
55
170
0.00
0.2
5.1
0.051 1.3
9-8208
116
40
210
5.33
0.187 4.8
70
4.8
55
170
0.00
0.2
5.1
0.064 1.6
9-8208
118
40
180
4.57
0.187 4.8
70
4.8
55
170
0.10
0.2
5.1
0.079 2.0
9-8208
116
40
150
3.81
0.19 4.8
70
4.8
55
170
0.30
0.2
5.1
0.125 3.2
9-8208
130
40
75
1.91
0.19 4.8
70
4.8
55
170
0.40
0.2
5.1
0.188 4.8
9-8208
132
40
60
1.52
0.187 4.8
70
4.8
55
170
0.60
0.2
5.1
0.250 6.4
9-8208
134
40
28
0.71
0.187 4.8
70
4.8
55
170
1.00
0.2
5.1
0.375 9.5
9-8208
143
40
11
0.28
0.187 4.8
70
4.8
55
170
NR
NR
NR
Type Torch: SL60 With Shielded Tip
Type Material: Mild Steel
Type Plasma Gas: Air
Type Secondary Gas: Single Gas Torch
Thickness
Tip
Output
Amperage Speed (Per Minute)
Standoff
Plasma Gas Press
Flow (CFH)
Pierce
Pierce Height
Inches mm (Cat. No.) Volts (VDC)
(Amps)
Inches
Meters
Inches mm
psi*
bar
Plasma Total** Delay (Sec) Inches mm
0.060 1.5
9-8210
124
60
250
6.35
0.19 4.8
75
5.2
90
245
0.00
0.2
5.1
0.075 1.9
9-8210
126
60
237
6.02
0.19 4.8
75
5.2
90
245
0.10
0.2
5.1
0.120 3.0
9-8210
126
60
230
5.84
0.19 4.8
75
5.2
90
245
0.10
0.2
5.1
0.135 3.4
9-8210
128
60
142
3.61
0.19 4.8
75
5.2
90
245
0.10
0.2
5.1
0.188 4.8
9-8210
128
60
125
3.18
0.19 4.8
75
5.2
90
245
0.20
0.2
5.1
0.250 6.4
9-8210
123
60
80
2.03
0.19 4.8
75
5.2
90
245
0.30
0.2
5.1
0.375 9.5
9-8210
132
60
34
0.86
0.19 4.8
75
5.2
90
245
0.50
0.2
5.1
0.500 12.7 9-8210
137
60
23
0.58
0.19 4.8
75
5.2
90
245
0.75
0.2
5.1
0.625 15.9 9-8210
139
60
14
0.36
0.19 4.8
75
5.2
90
245
NR
NR
NR
0.750 19.1 9-8210
145
60
14
0.36
0.19 4.8
75
5.2
90
245
NR
NR
NR
1.000 25.4 9-8210
156
60
4
0.10
0.19 4.8
75
5.2
90
245
NR
NR
NR
Type Torch: SL60 With Shielded Tip
Type Material: Stainless Steel
Type Plasma Gas: Air
Type Secondary Gas: Single Gas Torch
Thickness
Tip
Output
Amperage Speed (Per Minute)
Standoff
Plasma Gas Press
Flow (CFH)
Pierce
Pierce Height
Inches mm (Cat. No.) Volts(VDC)
(Amps)
Inches
Meters
Inches mm
psi*
bar
Plasma Total** Delay (Sec) Inches mm
0.06
1.5
9-8210
110
60
165
4.19
0.13
3.2
75
5.2
90
245
0.00
0.20 5.1
0.075 1.9
9-8210
116
60
155
3.94
0.13
3.2
75
5.2
90
245
0.10
0.20 5.1
0.120 3.0
9-8210
115
60
125
3.18
0.13
3.2
75
5.2
90
245
0.10
0.20 5.1
0.135 3.4
9-8210
118
60
80
2.03
0.13
3.2
75
5.2
90
245
0.10
0.20 5.1
0.188 4.8
9-8210
120
60
75
1.91
0.13
3.2
75
5.2
90
245
0.20
0.20 5.1
0.250 6.4
9-8210
121
60
60
1.52
0.13
3.2
75
5.2
90
245
0.30
0.20 5.1
0.375 9.5
9-8210
129
60
28
0.71
0.13
3.2
75
5.2
90
245
0.50
0.20 5.1
0.500 12.7 9-8210
135
60
17
0.43
0.19
4.8
75
5.2
90
245
0.75
0.20 5.1
0.625 15.9 9-8210
135
60
14
0.36
0.19
4.8
75
5.2
90
245
NR
NR
NR
0.750 19.1 9-8210
142
60
10
0.25
0.19
4.8
75
5.2
90
245
NR
NR
NR
