Tweco PC250 User Manual
Page 10
SPECIFICATIONS FOR PC250 PLASMA CUTTING SYSTEM (1445-0927)
Power Supply
Type
10 - 20 AMP Plasma Cutting System
Input Voltage
115V (60Hz)
Rated Output
20A / 40% Duty Cycle
Input Amperage
20A
Agency Approval
CSA
Maximum Output
20A
Cut Capacity
Most Materials up to
1
⁄
4
" (6.4mm)
Output Power Settings
Adjustable from 10 - 20 AMPs (Dial)
Panel LED Indicators
Green: On, Initiate Arc, Overvoltage / Red: Output Voltage /
Yellow: Air Pressure / Yellow: Temperature Indicator
Power Switch
Illuminated ON/OFF Switch UL/CSA Listed
Power Cord
6.5 ft (2m) 20Amp Power Plug
Plasma Gun
13 ft (4m) Firepower EL60
Ground Cable and Clamp
13ft (4m) 200A Clamp
Weight
~ 24 lbs (10.6 KG)
Power Supply Dimensions
17.72 x 5.91 x 12.20 inches (45 x 15 x 31 CM)
Torch
Configuration
70 Degree Head Angle
Leads Length
13 ft. (4m)
Current Rating
30 Amps, DC, Straight Polarity 100%
Duty Cycle
100%
Cutting Range
Most materials up to ⁄" (6.4mm)
Torch Parts
O-Rings, Electrode, Start Cartridge, Gas Distributor, Tip, Coil Spring,
Shield Cup
Gas Type
Air
Air Pressure
50psi - 200CFH
10
