Page 26
APPENDIX
A-2
Manual 0-4678
Appendix 2: Torch Connection
Torch
Switch
Negative / Plasma Lead
Torch Head
White
Black
Orange
Green
PIP
Switch
Torch Leads
To Power
Supply Adapter
Disconnect power and air. Lay unit
on its side. Remove access plate.
Pilot
Power Supply
Adapter
Negative / Plasma Lead
Art # A-04445
Work Cable
Pilot
Pilot
DETAIL
