PAGE 4 EVOLVE 55D PUMP OPERATION / MAINTENANCE MANUAL
1 INSTALLATION
1.1 UNPACKING
After unpacking, the pump should be checked for any damage that may have occurred
during shipment. Damage should be reported to the carrier immediately.
The following items should be included within the shipping container:
Qty Item Description
1 Pump Evolve 55D Pump
1 ME55D Operation/Maintenance Manual
1.2 UTILITIES / CONNECTION
It is recommended that the pump be positioned within 15
° from level to maintain self-priming
ability and pumping efficiency. Allow sufficient room for tubing connectors. The pump
mounts on a quick-change base for easy installation.
The pump has an exhaust location on the backside of the pump base. The exhaust location
requires 1/2” (12mm) minimum clearance behind the master head. Care should be taken to
prevent flooding the exhaust port when the pump is located in a wet bench plenum. For
remote exhaust connection see Section 1.3 below.
Air Inlet: 1/4” FNPT (3/8” Dia. [8mm] supply tube minimum).
Air Supply: 20-100 psig (.14 - .69 MPa) clean dry air or nitrogen (see Performance
Charts, Section 3.1).
Fluid Ports: Inlet/Outlet adaptor fittings and Surge Suppressor require torque application
during pump installation. See Section 2 for connection diagram and torque
values.
