PAGE 16 EVOLVE 55D PUMP OPERATION / MAINTENANCE MANUAL
4.5 PARTS LIST
ILL NO PART NO QTY DESCRIPTION PM YEAR # MATERIAL
1 BK005 2 Union Nut GFPP
1 AK003-01 2 PVDF Union Nut (optional) PVDF
2 AK116 2 Pilot Cap PP
3 AM020 2 Pilot Cap Seal PTFE
4 AK123 2 Smart Pilot Assembly 2 PEEK, PTFE, PPS
5 AK120 2 Pilot Sleeve Seal PTFE
6 AK097 2 Slip Washer PTFE
7 BK017 2 Muffler Assembly, Head 2 PP
8 AM040 2 Leak Port Plug PP
9 AM037 2 Leak Port Seal PTFE
10 AK182 4 Transfer Tube PFA
11 98003260 4 Jaco Fittings (¼” pipe to ½” tube) PP
12 BK004 2 Pump Head PP
13 BK020 2 Evolve Wear Resist Diaphragm PTFE/PFA
14 BK019 2 Evolve Diaphragm PTFE
15 1700B0041 2 Push Plate PTFE
16 AK004 1 Shaft 2 PTFE
17 98003079 2 Shaft Seal 2 PTFE
18 BK001 1 Pump Body PTFE
19 AM084 1 Damper Port Seal 2 PTFE
20 AM075 1 Damper Port Plug PTFE
21 AK026 2 Discharge Check Cage 2 PTFE
22 98001415 4 Check Ball 2 PTFE
23 98002334 4 Check O-Ring 2 PTFE
24 AK068 2 Suction Check Cage 2 PTFE
25 AK066 2 Suction Seat PTFE
26 AK153 2 Check Port Seal 2 PTFE
27 AK149 2 Suction Plug PTFE
28 AK205 1 Muffler Assembly, Base 2 PP
29 BK014 1 Distribution Control Base PP
30 AK058 1 Shuttle Sleeve Assembly Ceramic, PTFE
31 L0105 1 Detent Adapter PP
32 L0131 1 Spool Assembly, High Load 2 Ceramic, PEEK
33 L0113 1 Detent Cap Seal PTFE
34 L0104 1 Detent Cap PTFE
35 AK088 1 Mounting Base PP
36 AK108 1 Locking Lever PP
37 98003071 3 Screw, PP PP
38 98003080 1 ¼” NPT Plug PP
4.6 CLEAN-UP
To help remove potentially dangerous chemicals prior to service or shipment, the pump
should be flushed with DI water or disassembled and thoroughly cleaned. Allow DI water to
flush through the inlet and out the outlet to prevent pressure build up.
CAUTION: When handling pump, wear appropriate personal protection gear,
including safety glasses.
