744T User Guide and Technical Information
68
v. 2.67
Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
#
Setup Name
Setup Description
Setup Options
8
Rec: Track Names
Used to identify a track name which shows up in
iXML and BWF metadata
• Track A
• Track B
• Track C
• Track D
• Mix
• Boom
•
•
•
9
Rec: Take Name/Number
Numeric, auto-incrementing number used for take
identification.
with or without preceding 0’s> 10 Rec: Take Reset Mode Defines when take numbers are reset. Reset brings take number to <1>. • Never - take numbers do not reset - take resets when scene name is changed - takes reset on new day - takes reset on either change 11 Rec: Pre-Roll Time Selects the amount of pre-roll time the 744T will add to the beginning of each file. 0–10 sec. @ 48 kHz 0–5 sec. @ 88.2–96.096 kHz 0–2 sec. @ >96.096–192 kHz 12 Rec: Dither Selects whether to dither is added to 24 bit digital signals while recording 16 bit files. • Off • On (16 bit only) 13 Rec: Timer Start Sets a specific start time/date for unattended recording. Unit must be powered. 14 Rec: Timer Stop Set a specific time/date to stop recording. May be used with or without the Rec: Timer Start. May be set before the Timer Start time to temporarily stop recording and then resume recording with Timer Start. 15 Rec: Record Indicator Sets how the large display looks when the unit enters record. • Normal Numbers • Reverse Numbers • Flash Numbers 16 Rec: Record Pause Allows a recording to be stopped then continued without creating a new take or file. Time Code Mode must be set to Off to enable Record Pause. • Disabled • Enabled 17 Input: Routing Allows the user to setup their routing matrix among all available inputs and tracks. There are preset routings and three custom routings available. Pressing the input select key repeatedly will cycle through all preset routings. • 1 Þ A • 1 Þ A / 2 Þ B • 1 Þ A / 1 Þ B • 1 Þ A,B / 2 Þ A,B • 1 Þ A / 2 Þ B / 3 Þ C / 4 Þ D • 1,2,3 Þ A / 1 Þ B / 2 Þ C / 3 Þ D • Custom Route 1 • Custom Route 2 • Custom Route 3 18 19 Input 1: 48V Phantom Input 2: 48V Phantom Enables or disables 48 V phantom power on inputs 1 and 2. • Off • On - Mic • On - Mic and Line 20 Mic Inputs: Limiter Enables or disables the analog input limiter on input 1 and 2 mic preamps. • Disabled • Enabled 21 22 Mic Input 1: Low Cut Mic Input 2: Low Cut Enables the high-pass (low cut) filter to reduce sensitivity to low frequencies. • Disabled • Enabled 23 24 Mic Input 1: Low Cut Freq Mic Input 2: Low Cut Freq Selection of twelve high-pass filter frequency and slope combinations for microphone inputs. • 40, • 80, • 160, • 240 Hz @ 12 dB/oct • 40, • 80, • 160, • 240 Hz @ 18 dB/oct • 40, • 80, • 160, • 240 Hz @ 24 dB/oct 25 26 Mic Input 1: Gain Range Mic Input 2: Gain Range Selects the sensitivity of the microphone input. Low sensitivity is used for very loud and/or very hot microphones. • Normal • Low • Normal, fades to off • Low, fades to off
• When scene is changed
• When daily folder changes
• Either scene or daily
Primarily accessible from the Input Select Key.
