10.1 Legend
100
body
117
thrust flange
122
inlet nozzle
124
pressure ring
204
plug
205
seat
206
bellows
237
lifting aid
238
lifting lever
305
bearing guide
306
stem guide
307/1
guide bush
308
insert sleeve
395
axial-needle roller cage
396
axial-washer
400/1
o-ring
420
thrust ring, two pieces
513
spring bonnet
534
stem nut
535
lifting cap
536
upper spring plate
537
lower spring plate
538
adjusting screw
539
locking plate
554/2
washer
555
centering nut
561/1
grooved pin
802
spindle
900/1
ring bolt
901/x
hex. screw
902/x
stud screw
914/1
hex. Socket screw
918/1
threaded rod
920/x
hex. nut
920/3
hex. nut, plain
927/1
cap nut
929/1
prevailing torque type hex. nut
932/x
snap ring
934/1
lock washer
935/1
lead seal
936/x
toothed lock washer
938/1
hex. head screw plug
939/1
spring type pin
952/1
pressure spring
Option blocking screw
901/3
hex. screw
918/1
threaded rod
927/1B cap nut
929/2
prevailing torque type hex. nuts
Option gas-tight design
238
lifting lever
400/4
o-ring
Option signal transmitter
540
support, signal transmitter
includes:
400/2
o-ring (design with blocking screw)
400/3
o-ring
541
support, upper part
542
support, lower part
901/4
hex. screw
(design with blocking screw)
904/1
setscrew
939/2
spring-type pin
805
stem extension
859
signal transmitter
920/4
hex. nut
Option travel stop
508
travel stop
Option design for highly permeating media
307/2
guide bush
860
spring turn unit
