9
REVEL Concerta B12
Owner’s Manual
Unpacking
(continued)
2. Without allowing the top flaps to close,
stand the packing carton upside-down
as shown in Figure 1 (above).
3. Lift the packing carton off of the
subwoofer as shown in Figure 2
(above). Use caution to avoid dam-
aging the cabinet and objects locat-
ed above the packing carton. At
this point, the subwoofer will be
upside-down.
Note
While the subwoofer is upside-down, it is
recommended to adjust the spike feet if
the B12 will be placed on a carpeted
floor. Refer to the Feet and Optional
Spikes section that begins on page 17
for instructions.
4. Grasping the sides of the cabinet, place
the B12 on its side. Then, place the B12
in the upright position.
5. When the B12 is in the upright posi-
tion, remove the Owner’s Manual,
Warranty Card and microfoam sheet.
1
2
3
Figure 1: Unpacking the B12 Figure 2: Lifting the Carton
Figure 3: Packing Materials
