Revel B12 - Manual (Page 22)

Value Specification Value Specification
22
Frequency Response
Maximum Amplifier
Output
(20Hz-150Hz with no
more than 0.1% THD)
+/- 0.5dB in the pass
band
650 watts
Specifications are subject to change without notice.
Low Pass Crossover
Frequencies 50Hz-175Hz,
24dB/octave,
continuosly variable
SPECIFICATIONS
Width
14.10 inches (35.81cm)
(including feet)
Height
13.12 inches (33.32cm)
Depth 15.21 inches (38.63cm)
(not including grille)
15.96 inches (40.54cm)
(including grille)
Weight 63.9 pounds (29.0kg)
(not including grille)
64.4 pounds (29.2kg)
(including grille)
Low Frequency
extension (anechoic) -3dB at 28 Hz
-6dB at 25 Hz
-10dB at 23Hz
Power 120 Vac @ 60Hz, 577 Wrms
230 Vac @ 50Hz, 600 Wrms
REVEL Concerta B12
Owner’s Manual
