VirtualDJ 8 – Reloop Terminal Mix 4 9
26. Each one of the 4 Sampler buttons triggers a sample from the selected Sampler
Bank of VirtualDJ8. The buttons will control samples 1 to 4 (or 5 to 8 if the 2 nd bank is
selected).
If a bank has less than 9 samples, both sides of the Terminal Mix 4 will control the
same samples. If a bank has more than 8 samples, the left side of the Terminal Mix 4
will control samples 1 to 8 and the right side samples 9 to 16.
The Leds of the Sampler buttons will be turned on if a sampler slot is available
(loaded) and will blink is triggered.
Press the buttons to trigger a sample. Depending on the selected trigger mode, use
SHIFT and the same pads to stop the sample.
E. MIXER & BROWSER
27. CROSSFADER. Blends audio
between the channels assigned to
the left and right side of the
crossfader.
28. VOLUME. Adjust the Volume of each
channel.
29. LOAD. Press these buttons to load
the selected track from the Browser
to decks 1 to 4. The LED of the
button will be on if the deck is loaded.
Hold the same button for more than 2
seconds to unload the same deck.
Hold SHIFT down and then press
one of these buttons to enable the
Fader Start on a deck.
30. PFL. Press these buttons to send
one (or more) channel to the
Headphones Output channel.
31. FILTER. Use this knob to apply a
High/Low Pass Filter to the deck. In
middle position no filter is applied.
32. EQ LOW. Adjust the Low (Bass)
frequencies for each mixer channel.
33. EQ MID. Adjust the Mid frequencies
for each mixer channel.
34. EQ HIGH. Adjust the High (Treble)
frequencies for each mixer channel.
