RCBS The Grand - Manual (Page 18)

15
# Description Part # Qty
1 SS Frame 789000 1
2 SS Top Plate 789001 1
3 SS Support Rod 789023 2
4 SS Support Rod Turned 789031 1
5 3/8-16 x 1 Flat Head Cap Screw 188750 3
6 Link Pin Left 788258 1
7 Link Pin Right 788257 1
8 SS Ram 789020 1
9 Detent Ball 187152 3
10 Detent Spring 187153 3
11 1/4-28 x 3/8 Socket Head Set Screw 187219 1
12 SS Lock Out Pin 789022 1
13 Link 188719 2
14 SS Toggle Block 789002 1
15 7/16-20 Nyloc Nut 188108 2
16 Toggle Block Pin 788256 1
17 SS Ram Pin 789021 1
18 Handle 786862 1
19 Handle Ball 109121 1
20 5/8-18 Hex Nut 109136
21 SS Charge Bar 789018 1
22 SS Powder Bushing SEE CHART
23 SS Shot Bushing SEE CHART
24 SS Shut Off Plate Powder 789062 1
25 SS Shut Off Plate Shot 789010 1
26 Rubber Washer 189039 1
27 10-24 x 1/2 Flat Head Cap Screw 189077 4
28 10-24 x 1-1/4 Socket Head Set Screw 189062 2
29 10-24 Nyloc Nut 189063 2
30 SS Shut Off 189019 2
31 SS Spring 189061 2
32 SS Self Locking Pin 189036 2
33 8-32 x 1/4 Button Head Cap Screw 188041 10
34 SS Index Shaft Bracket 789006 1
35 8-32 x 3/4 Button Head Cap Screw 187221 1
36 8-32 Nyloc Nut 189078 1
37 SS Charge Bar Index Shaft 789047 1
38 SS Charge Bar Push Rod Upper 789045 1
39 1/4-28 Hex Nut 109604 1
40 SS Charge Bar Push Rod Lower 789046 1
41 1/4-20 Nyloc Nut 189072 1
42 3/16 x 1 Clevis Pin 189038 1
43 SS Index Arm 789009 1
44 SS Powder Funnel 789011 1
45 SS Powder Hopper 189031 1
46 SS Powder Hopper Cap 189029 1
47 SS Powder Baffle 189037 1
48 SS Shot Funnel 789012 1
49 SS Shot Hopper 189030 1
50 SS Shot Hopper Cap 189028 1
51 SS Spent Primer Bottle Cap 789016 1
52 SS Decap Tube 789030 1
53 SS Spent Primer Bottle 189032 1
54 1/4-28 x 1 Flat Head Cap Screw 189075 3
55 1/4-28 Hex Nut 189604 2
56 SS 10/32 x 1/4 Socket Head Set Screw 109099 1
57 SS Spring 189055 1
58 SS Primer Seater Casting 189026 1
59 6-32 x 5/8 Socket Head Cap Screw 198964 4
60 1/4-28 x 1/2 Hex Head Bolt 189067 1
61 SS Primer Transfer Bar 789102 1
62 SS Spring 189054 1
63 1/8 x 1 Roll Pin 189079 1
64 6-32 x 1/4 Button Head Cap Screw 189066 6
65 SS Primer Sleeve 189025 1
66 SS Primer Plug 789034 1
67 SS Case Holder Plate 12 GA. 789004 1
67 SS Case Holder Plate 20 GA. 789110 1
68 SS Case Holder Top Plate Cap 789005 1
69 SS Case Holder 12 GA. 189015 16
69 SS Case Holder 20 GA. 789109 16
70 SS Spring 189052 16
71 8-32 x 5/16 Button Head Cap Screw 186147 9
72 SS Eject Rod Holder 12 GA. 789054 1
72 SS Eject Rod Holder 20 GA. 789119 1
73 SS Eject Rod 789055 1
74 3/8-16 x 1-1/2 Socket Head Cap Screw 189074 1
75 SS Shell Plate Holder 789003 1
76 SS Discharge Chute 789017 1
77 1/4-28 x 1/4 Button Head Cap Screw 189073 2
78 SS Green Wad Box 189033 1
Wad Carrier Assy 12 GA. 789078, 20 GA. 789132
79 SS Wad Carrier Bottom 789008 1
# Description Part # Qty
80 SS Wad Carrier Top 789007 1
81 5-40 x 3/4 Socket Head Cap Screw 189068 1
82 5-40 Hex Nut 189069 1
83 10-24 Hex Nut 189086 1
84 10-24 x 1-1/4 Socket Head Set Screw 189062 1
85 SS Spring 189058 1
86 SS Wad Guide 12 GA. 189016 1
86 SS Wad Guide 20 GA. 189017 1
87 SS Spring 189057 3
88 8-32 Flat Washer 189080 2
89 SS Primer Drop Tube Assy 789096 1
90 SS 5/8-18 Lock Ring 789059 1
91 SS Transfer Bar Actuator 789033 1
92 1/4-28 x 1/4 Socket Head Set Screw 189076 1
93 SS Primer Dispenser Collet 189024 1
Primer Tray Assy 789087
94 SS Primer Tray Bottom 189027 1
95 SS Primer Tray Frame 789014 1
96 10-32 x 1/4 Socket Head Cap Screw 187687 2
97 SS Primer Tray Base 789015 1
98 10-32 x 5/8 Socket Head Cap Screw 186624 2
99 SS Primer Feed Bar 189034 1
100 SS Spring 189061 1
101 SS Primer Shut Off Pin 789039 1
102 SS Primer Tray Lid 189035 1
Size Die Assy 12 GA. 789071, 20 GA. 789128
103 SS Size Die Bushing 789025 1
104 SS Spring 189053 1
105 SS Hull Extractor 12 GA. 789029 1
105 SS Hull Extractor 20 GA. 789112 1
106 SS Decap Rod Assy 789072 1
107 SS Size Die Body 789024 1
108 SS 1-3/8-12 Lock Ring 789058 1
109 SS Size Ring 12 GA. 789026 1
109 SS Size Ring 20 GA. 789111 1
Primer Body Assy 12 GA. 789074, 20 GA. 789129
110 1/2-13 Hex Nut 189081 2
111 Snap Ring 180052 1
112 SS Primer Body Bushing 789038 1
113 SS Primer Body 789037 1
114 SS Primer Stem Washer 789063 1
115 SS Spring 189056 1
116 SS Primer Stem Assy 12 GA. 789075 1
116 SS Primer Stem Assy 20 GA. 789130 1
Powder Tube Assy 789076
117 SS Upper Drop Tube 789101 1
118 SS Drop Tube Lock Ring, Brass 789056 1
119 SS Powder Tube Lower 789042 1
Shot Drop Tube Assy 12 GA. 789077, 20 GA. 789131
117 SS Upper Drop Tube 789101 1
118 SS Drop Tube Lock Ring, Brass 789056 1
122 SS Shot Tube Lower 12 GA. 789044 1
122 SS Shot Tube Lower 20 GA. 789115 1
Wad Starter
120 3/8-16 Hex Nut 189082 1
121 SS Wad Starter 12 GA. 789043 1
121 SS Wad Starter 20 GA. 789114 1
Crimp Starter Assy 12 GA. 789091, 20 GA. 789133
120 3/8-16 Hex Nut 189082 1
123 SS Crimp Start Rod 789048 1
124 SS Crimp Starter 12 GA. 8 POINT 189021 1
124 SS Crimp Starter 20 GA. 8 POINT 189023 1
125 SS Crimp Starter 12 GA. 6 POINT 189020 1
125 SS Crimp Starter 20 GA. 6 POINT 189022 1
126 8-32 x 1/2 Socket Head Cap Screw 187227 1
Crimp Closer Assy 12 GA. 789082, 20 GA. 789134
120 3/8-16 Hex Nut 189082 2
127 SS Crimp Closer Washer 789051 1
128 SS Spring 189059 1
129 SS Crimp Closer Sleeve 12 GA. 789049 1
129 SS Crimp Closer Sleeve 20 GA. 789116 1
130 SS Crimp Closer Plunger 12 GA. 789050 1
130 SS Crimp Closer Plunger 20 GA. 789117 1
Final Crimp Assy 12 GA. 789083, 20 GA. 789135
120 3/8-16 Hex Nut 189082 2
131 SS Final Crimp Rod 789052 1
132 SS Final Crimp Sleeve 12 GA. 789053 1
132 SS Final Crimp Sleeve 20 GA. 789118 1
133 SS Wad Box Bracket 789013 1
134 #8 x 1/2 Wood Screw 189064 2
Not Pictured
SS Drain Tube 789019 1
122 SS Lower Shot Tube - Long 789100 1
THE GRAND PARTS LIST • NOVEMBER 2003
2429_RCBS Grand Instr 1/31/05 2:34 PM Page 18
