8
VistaBeam Yoke Mount
The yoke has a ½” hole to accept industry
standard hardware.
The VistaBeam 610 and 310 Yoke Mount
fixtures can hang from a junior pipe hanger using
a Junior Pin Assembly for Yoke (MTP-I80), sold
separately.
MTP-I80 Junior Pin Assembly for Yoke
Center Mount Speed-Rail Rigging
The mount fittings are U.S. industry standard
“Speed Rail” 1 ¼” fittings. They accept a 1 5/8”
outside diameter pipe.
These fittings enable custom frames to be
constructed for special rigging applications
such as multiple fixture hangs.
Warning: Use only M5 X 10mm screws (supplied) to assemble yoke.
Note that threads on the fixture are self-locking and may seem tight.
Replacement screws: Part No. 2020127
Recommended torque setting:
USA: 18 lb-in
Metric: 2 Nm
