Kino Flo VistaBeam 600/300 DMX - Manual (Page 6)

6
Applying Gel to Frame
Inserting Louver
Mount Option / Rope Hang
A B
A) The Gel Frame comes with Gel clips. Cut the gel to size and use the clips to
fasten the gel to the frame. Note: It is recommended to attach one clip on all four
sides and two clips near all four corners of the Gel Frame.
B) Another method is to apply transfer tape directly to the gel frame. The clips are
not necessary when taping the gel.
Align the pins of the louver with the outer (farthest from lamps) receptacle holes
on the Accessory Holder. Pull back the pins and release into the hole to secure
the louver.
The large holes on the Accessory
Holder can be used as rigging points,
for example, a 4-point rope hang.
