1.0 Overview & Orientation
The AccUView Wastewater process transmission monitor allows for the UV transmission
measurement of process water on-line. The sensor features a low pressure lamp operating
at 254 nm. The unit includes a sampling pump capable of drawing water from 3.6m (12
feet) down. The entire unit is enclosed in a weather resistant stainless steel enclosure.
A unique feature of the instrument is the ultrasonic cleaning. Refer to section 8.1 for more
information.
1.1 Unpacking and Inspection of the Instrument and Accessories
The table below indicates the items in the monitor shipment.
Item Quantity
AccUView Wastewater Monitor 1
Instruction Manual 1
Desiccant Pack 1
Quartz Cuvette with Ultrasonic Transducer (Single Pack) 1
Replacement Quick Connect Flow Through Unit 1
100 %T Calibration Standard 1
AccUView Wastewater Installation Kit * 1
* Note – Installation Tubing Kit includes:
15.24 meters (50 feet) tygon tubing
1 foot strainer
Cabinet mounting kit
Remove the instrument from the packing carton. Carefully inspect all items to ensure that
no visible damage has occurred during shipment. If the items received do not match the
order, please immediately contact the local distributor or the HF scientific Customer
Service department.
