Specifications
Measurement Range
0 – 100.0 %T
Reproducibility ± 0.1 %T
Resolution
0.1 %T
Accuracy ± 1.0 %T (30%T to 100%T)
Pump Draw
3.6 meters (12 feet)
Flow Rate 0.5 – 1.0 liter/min depending on lift required
Path Length 22 mm(Readings corrected to 10 mm)
Light Source Low Pressure Mercury Lamp – 254nm
Display Multi-Line Liquid Crystal Backlit Display
Alarm Programmable, 120-240VAC 2A Form C Relay
Analog Output Powered loop isolated 4-20 mA, 600
Ω drive
Communications Port Optional Bi-directional RS-485 with Modbus
Maximum Water Pressure 1380 kPa (200 psi.) with integral pressure regulator
Operating Temperature
0°C – 50°C (32°F – 122°F)
Model 19571C: -10°C – 50°C (14°F – 122°F)
Wetted Materials
Nylon, Quartz, Silicon, Polypropylene, Stainless Steel
Sample Temperature Range
0°C – 50°C (34°F – 122°F)
Power Supply 100– 240 VAC, 47 – 63 Hz, 80VA
Insulation Rating Double Insulated, Pollution Degree 2, Overvoltage Category II
Environmental Conditions Not recommended for outdoor use.
Altitude up to 2000 meters
Up to 95 % RH (non-condensing)
Enclosure Rating Designed to meet IP 66 /NEMA 4X
Regulatory Compliance
And Certifications CE Approved, ETL listed to UL 61010B-1 &
ETL Certified to CSA 22.2 No. 1010-1-92
Shipping Weight
23.6 kg (52 lbs.)
Warranty 1 Year from date of shipment
